Tractel J5 Tirfor Lever operated Winch c/w 6.5mm dia x 10 mtr wire rope & Hook plus 2 Wire Slings & Operating Lever WLL: 500 kgs -: 203.102.005 .

Tractel J5 Tirfor Lever operated Winch c/w 6.5mm dia x 10 mtr wire rope & Hook plus 2 Wire Slings & Operating Lever WLL: 500 kgs -: 203.102.005 .

Regular price £674.25 GBP
Regular price £674.25 GBP Sale price £674.25 GBP
Sale Sold out
Shipping calculated at checkout.

Product Code

SKU:203.102.005

Quantity

In stock

The Jockey™ hoist is a manual lifting and pulling device. It is a versatile and portable multi-purpose device. It can be used for lifting and pulling, but also for lowering, tensioning and securing loads in all directions. Spare shear pins for overload protection are supplied as standard.

■ Light and compact

■ Equipped with standard accessories

■ Unlimited wire rope length

■ Reliable and easy to use

■ Working load can be increased by using sheave blocks

■ Overload protection

It is supplied with a 10 metre long wire rope and two wire slings.
The J5 is perfect for pulling small Caravans Trailers & Boats up a slope or steep drive.

This machine must not be used for Man Riding applications.

Applications & Advice

Technical Info

Dimensions

Rope Length: 10 mtrs
Rope Diameter: 6.5mm
A: 19mm
B: 370mm
C: 313mm
D: 65mm
E: 146mm
F: 12mm
G: 52mm
H: 245mm
I: 500mm
