• A polished stainless steel rectangular eyeplate with four holes for mounting and a curved loop at the top on a white background.
  • Rectangular eyeplate and technical drawing with dimensions on a white background
1 2

8mm x 50mm A2-AISI 304 Stainless Steel Rectangular Eyeplate - 105.102.812 .

8mm x 50mm A2-AISI 304 Stainless Steel Rectangular Eyeplate - 105.102.812 .

£5.14 GBP
£5.14 GBP £5.14 GBP
Sale Ausverkauft
Versand wird beim Checkout berechnet

Product Code

105.102.812

280 auf Lager
  • AISI 304 grade stainless steel rectangular eye plate
  • High corrosion resistance
  • Versatile & adaptable component
  • Polished stainless finish
  • Order any quantity with no minimum order charge

This high quality easy to fit stainless steel rectangular eye-plate is suitable for balustrading fixings, garden design, marine & architectural projects. Requires 4 x 5mm bolts or screws to install.

Applications & Advice

8mm x 50mm A2-AISI 304 Stainless Steel Rectangular Eyeplate - 105.102.812 Detailed Description (SCA)

AISI 304 grade stainless steel rectangular eyeplate

High corrosion resistance

Versatile & adaptable component

Polished stainless finish

Order any quantity with no minimum order charge

This high quality easy to fit stainless steel rectangular eyeplate is suitable for balustrading fixings, garden design, marine & architectural projects. Requires 4 x 5mm bolts or screws to install.

Dimensions

A: 8mm
B: 23mm
C: 3mm
D: 5.5mm
E: 25mm
F: 35mm
G: 20mm
H: 40mm
I: 50mm
