WH L4 Lever Hoist - 1.5mtr HOL
WH L4 Lever Hoist - 1.5mtr HOL
Product Code
SKU:857.033.080
En existencias
No se pudo cargar la disponibilidad de retiro
1.5mtr Height of Lift
The William Hackett L4 Lever Hoist is designed, manufactured and proof load tested in the UK.
This tough and robust lever hoist can lift or pull and is great for every day use, one-off lifts or as part of a fleet. We provide a full range of spare parts and can offer training on safe use and inspection.
The Shipyard Hook adaptation is available on request.
Alternative heights of lift available upon request.
| WLL Range: | 800kg - 15t |
| Proof Load Test: | 1.5 X WLL |
| Safety Factor: | 4:1 |
| Temp Range: | -20°C to +120°C |
Applications & Advice
Applications & Advice
Lever hoists are designed to be used with the operator beside the hoist, able to lift vertical loads up to 45°. This provides a distinct advantage as there is no hand chain to obstruct the lifting operation, ideal for use in pulling and tensioning applications.
Used widely across the construction industry and multiple sectors.
Pre-use checks and maintenance should always be carried out with a statutory inspection under LOLER every 12 months.
Dimensions
Dimensions
Downloads
Downloads
Technical Information
Technical Information
LIGHT LOAD CAPABILITY: the WH L4 is tested and certified at 2% of the lever hoist rated capacity.
TWIN PAWL: double safety; fitted as standard.
SAFETY LATCHES: the WH L4 lever hoist top and bottom hooks are fitted with heavy duty cast steel latches. The latch and hook tips are integrated creating a strong and robust hook closure.
HOOK OVERLOAD AND TRACEABILITY MARKS: hooks have overload indicator marks either side of the hook throat (500kg to 10t). Both top and bottom hooks are embossed with a batch code, manufacturer's mark and the working load limit for full traceability and compliance to international standards.
HOOK HOUSING: secured with socket head cap screws/hex head bolts and nyloc locking nuts to allow full inspection.
FLEETING/CROSS HAULING: the WH L4 lever hoists are tested and certified for fleeting or cross hauling applications up to 45° from the vertical without deration.
LOAD CHAIN: the WH L4 lever hoists are fitted with load chain that fully complies with international standard BS EN818-7 Grade T (8).
OVERLOAD LIMITER: available as an option upon request.
TOP AND BOTTOM HOOK ADAPTORS: available as an option upon request.
TRAVELLING END STOP: available as an option upon request.
MANUFACTURED AND PROOF TESTED in the U.K.
Standards:BS EN13157:2004 + AI:2009, ASME B30.21-2014, AS1418.2-1997, SANS 1636:2007, NORSOK R-002: 2017
