YaleERGO 360® Standard & UT Ratchet lever hoist

YaleERGO 360® Standard

• The lightweight, high-strength aluminium housing with powder coating and high-quality bearings offer a long service life
• The hand lever with integrated snap crank ensures ideal power transmission and enables a 360° working range.
• Display of the operating direction or free chaining in the viewing window of the hand lever.
• The covered load pressure brake remains free of dirt and moisture
• Standard free chaining device to quickly attach the load or to pull the chain through the hoist in both directions.
• Chain guide and stripper are made of robust cast iron and zinc plated to protect against corrosion.
• Alloyed steel link chain with zinc-plated resp. yellow chromated finish, in accordance with national and international standards and regulations.
• Rotatable, forged top and load hooks and casted safety latches provide reliable and safe load suspension. The screwed top hook cross bars and bottom blocks are allowed for easy maintenance.

YaleERGO 360® UT (with safety gear)

• The YaleERGO 360 ® UT has a unique, automatically locking safety device to prevent a sudden drop (patented). It guarantees permanent monitoring and is active during operation as well as during inactive moments without the user having to activate it. In case of emergency, i.e. after failure of the load pressure brake and consequently exceeding the specified speed, the safety gear will automatically activate. It safely absorbs the load, preventing the creation of larger dynamic forces which could cause further damage.
•  housing optimised for outdoor applications prevents a build up of water and the influence of moisture in extreme conditions. External components such as the chain guide and the stripper are zinc plated. Some of the internal moving parts such as the drive pinion, the ratchet pawl, the load chain wheel and the ratchet are MKS coated

**Price at standard lift (1.5m)
