KL50 Kwik Loc Cable Grip

SWL: 15 kg

Suitable for use with 1 - 1.25mm, 7x7 or 7x19, Galvanised or Stainless Steel cable.

Kwik Locs are manufactured from Zamak 5 zinc alloy for the main body with internal stainless steel spring and sintered steel locking wedge(s) making them perfect for use indoors or outdoors.

This lightweight, quick and easy to fit cable grip is a safe, tool-free option for joining, tensioning & creating loops in cables on site.

For further help or information, please contact a member of our Sales Team.

Applications & Advice

Typical applications:

Suitable areas of use include, but are not limited to:

Electrical containment
Lighting and audio
HVAC and mechanical services
Signage, display, screens and partitions
Acoustic and radiant heat panels
Bracing
Catenaries

This product is also excellent with 7x19 cable constructions but make sure you apply the 5:1 factor of safety based upon the size and construction of cable selected. We would recommend you use wire rope cutters for neat cable ends to ensure easy installation.

Zip-Clip has five different systems which are allocated a letter to differentiate between the available safe working loads (SWL).

Each system comprises a specific wire rope diameter and is supplied with the required Zip-Clip device.

Safe Working Loads

G 15 kg

S 50 kg

Y 120 kg

P 300 kg

N 500 kg

*Please note that all stated working loads and certifications are based on the product being used in conjunction with the High Tensile Zip-Clip Rize Wire
